NACHI ตลับลูกปืน 6215 C3 NACHI Open Deep Groove Ball Bearing ขนาด 75x130x25mm แบรนด์ ญี่ปุ่นแท้ คุณภาพสูง

NACHI ตลับลูกปืน 6215 C3 NACHI Open Deep Groove Ball Bearing ขนาด 75x130x25mm แบรนด์ ญี่ปุ่นแท้ คุณภาพสูง

NACHI ตลับลูกปืน 6215 C3 NACHI Open Deep Groove Ball Bearing ขนาด 75x130x25mm แบรนด์ ญี่ปุ่นแท้ คุณภาพสูงSingle row deep groove ball bearing 75mm inside x 130mm outside x 25mm widthNACHI Single row deep groove ball bearings are used in a wide variety of applications, they are simple in design, non-separable, suitable for high speeds and are robust in operation, and need little maintenance. Deep raceway grooves and the close conformity between the raceway grooves and the balls enable deep groove ball bearings to accommodate axial loads in both directions, in addition to radial loads.Single row deep groove ball bearings are manufactured as open type (unsealed), sealed and shielded, the most popular sizes of deep groove ball bearings are also produced in sealed versions with shields or contact seals on one or both sides, the bearings with shields or seals on both sides are lubricated for life and are maintenance free. A sealed bearings seals has contact on the bearings inner and outer, a shielded bearings shield has contact on the outer only, and Shielded bearings are primarily intended for applications where the inner ring rotates. If the outer ring rotates, there is a risk that the grease will leak from the bearing at high speeds.Principal DimensionsInside diameter d: 75mmOutside diameter B: 130mmWidth D: 25mmBasic Load RatingsDynamic: 68,9knStatic: 49knSpeed RatingsReference speed: 10000 r/minLimiting speed: 6700 r/minDimensions mmd1: 92,1D1: 113D2: 117r1,2 min: 1,5

NACHI ตลับลูกปืน 6215 C3 NACHI Open Deep Groove Ball Bearing ขนาด 75x130x25mm แบรนด์ ญี่ปุ่นแท้ คุณภาพสูง

Single row deep groove ball bearing 75mm inside x 130mm outside x 25mm width

NACHI Single row deep groove ball bearings are used in a wide variety of applications, they are simple in design, non-separable, suitable for high speeds and are robust in operation, and need little maintenance. Deep raceway grooves and the close conformity between the raceway grooves and the balls enable deep groove ball bearings to accommodate axial loads in both directions, in addition to radial loads.

Single row deep groove ball bearings are manufactured as open type (unsealed), sealed and shielded, the most popular sizes of deep groove ball bearings are also produced in sealed versions with shields or contact seals on one or both sides, the bearings with shields or seals on both sides are lubricated for life and are maintenance free. A sealed bearings seals has contact on the bearings inner and outer, a shielded bearings shield has contact on the outer only, and Shielded bearings are primarily intended for applications where the inner ring rotates. If the outer ring rotates, there is a risk that the grease will leak from the bearing at high speeds.

Principal Dimensions
Inside diameter d: 75mm
Outside diameter B: 130mm
Width D: 25mm

Basic Load Ratings
Dynamic: 68,9kn
Static: 49kn

Speed Ratings
Reference speed: 10000 r/min
Limiting speed: 6700 r/min

Dimensions mm
d1: 92,1
D1: 113
D2: 117
r1,2 min: 1,5
